How to Calculate Fabric Consumption for Woven Bottom

Introduction:
Fabric consumption for the woven bottom is an important task for apparel merchandisers. If the calculation is not correct then the company will face to huge loss and reputation also fall. This article will be helpful for beginners who are involved in the garment sector. In the garment sector, there are two types of merchandise, one is woven merchandise (Such as Shirt, Pant, Blouse, etc.) & the other one is knit merchandise (T-shirt, Polo shirt, Fashion knit, Sweater Etc ). In this article, I will explain fabric consumption for the woven bottom.

Calculate Fabric Consumption for Woven Bottom
Fig: Bottom and their parts

How to calculate fabric consumption for woven bottom:

Normally, a woven bottom consists of the following parts-

  1. Body parts,
  2. Pocket,
  3. Pocketing Fabrics,
  4. Belt Loop.

For calculating fabric consumption for woven bottom we can follow the below measurement chart:

Actual Length in  (inch) Allowance Measurement with Allowance
Total Length including Waist Height 44” 2” 46”
Waist Width 35” 2” 37”
HIP 45” 2” 47”
Thigh 18” 2” 20”
Bottom Width 13” 2” 15”
Back Pocket Length 7” 1” 8”
Back Pocket Width 6” 1” 7”
Belt Loop Length 1.5” 0.5” 2”
Belt Loop Width 0.5” 0.5” 1”
Pocket Bag Length 7” 1” 8”
Pocket Bag Width 6” 1” 7”

We can find fabric for every piece in the following way:
We can let,
Fabric width = 56”
Wastage = 10%

We can consider the following formula for fabric consumption,

…..Length × width × No. of Parts × 12
= ………………………………………………….. (yds per dozen)
…………….Fabric Width × 36

1. Fabric consumption for the Body Parts:

Here, we will apply the following formula (per dozen),

….Body Length × Body width × No. of Parts × 12
= ………………………………………………………………….. (yds)___________(A)
……………………….Fabric Width × 36

Now,
Body Width,

={(Waist Width + HIP) / 2} + {(Thigh + Bottom) / 2}
={(37 +47) /2} + {(20 + 15) /2}
= 59.5”

Now, from equation (A), we get-

….46 × 59.5 × 4 × 12
= …………………………. yds per dozen.
…………..55 × 36

= 66.352yds per dozen__________________________ (B)

So, the fabric needed for the body parts is 66.352yds per dozen.

2. Fabric consumption for the Back Pocket (2pcs):

Here, we will apply the following formula (per dozen),

….Back Pocket Length × Back Pocket width × No. of Parts × No. of pocket × 12
= ………………………………………………………………………………………………………………. yds
…………………………………………..Fabric Width × 36

….8 × 7 × 2 × 2 × 12
= ………………………… yds per dozen.
…………..55 × 36

= 1.36yds per dozen____________________(C)

So, the fabric needed for the back pocket is 1.36yds per dozen.

3. Fabric consumption for the Pocket Bag (2pcs):

Here, we will apply the following formula (per dozen),

….Pocket Bag Length × Pocket Bag width × No. of Parts × No. of pocket × 12
= …………………………………………………………………………………………………………… (yds
…………………………………………..Fabric Width × 36

……8 × 7 × 4 × 2 × 12
= ……………………………yds per dozen.
………….55 × 36

= 2.72yds per dozen ____________________ (D)

So, the fabric needed for the pocket bag is 2.72yds per dozen.

4. Fabric consumption for the Belt Loop (5pcs):

Here, we will apply the following formula (per dozen),

….Belt Loop Length × Belt Loop width × No. of Parts × No. of Belt Loop × 12
= …………………………………………………………………………………………………………… yds
……………………………………….Fabric Width × 36

….2 × 1 × 2 × 5 × 12
= ………………………… yds per dozen.
…………..55 × 36

= 0.121yds per dozen__________________(E)

So, the fabric needed for the belt loop is 0.121yds per dozen.

Now,

By adding the equation B, C, D and E we can get the total fabrics consumption for the above order (per dozen)-
=(B +C + D + E) yds per dozen
=(66.352 + 1.36 + 2.72 + 0.121) yds per dozen.
= 70.553yds per dozen.
= 5.88 yds per pc

So, fabric consumption per pc is 5.88 yds.
