Twist per inch of yarn varies from count to count of yarn:
Basically, the lighter or finer the yarn, yarn count numbers small, the more the twist per inch and vice versa. The twist for yarns having a small degree of twist varies inversely as to the square root of their count. In this article, we will know about the relationship of twist, yarn count, and twist change pinion in jute spinning. Here,
(a) More Twist Per Inch on the yarn—small yarn count
(b) Less Twist Per Inch on the yarn— big yarn count
Relationship of Twist, Yarn Count,
and Twist Change Pinion in Jute Spinning
Example 01:
If 9 lbs per spyndle hessian weft yarn have 3.8 TPI, what will be the TPI for 10lbs/spyndle hessian weft yarn?. Both the yarns having the same degree of twist.
Answer:
Let T be the twist per inch for 10 lbs/spindle yarn.
………..√9………..T
Then, ……. = …………
……….√10………3.8
Or, √10 × T= √9 × 3.8
Or, 3.162 × T = 3 × 3.8
……………….3 X 3.8
Then, T = ……………..
…………………3.162
= 3.6 (ANS)
(a) More Twist Per Inch on the yarn—- small TCP
(b) Less Twist Per Inch on the yarn—- big TCP
From (a) and (b) above, it is observed that twist has an inverse relation both with the square root of yarn count and TCP. Therefore, square roots of yarn count have a direct relation with TCP.
Example: 02:
48 teeth TCP for 9 lbs per spyndle hessian weft yarn: what TCP for 10 lbs per spyndle hessian weft yarn? Both the yarn having the same degree of twist.
Answer:
Let P be the TCP for 10lbs yarn,
…………48………√9
Then, …….. = …………
…………..P……..√10
Or, P × √9 = 48 × √10
Or, P × 3 = 48 × 3.162
……………..48 × 3.162
Then, P = ……………..
……………………3
= 50.572, say, 51 teeth (ANS)
Author of this Artcle: Engr Avijit Dey Production Officer Fabian Group, Chittagong Mobile: 01836124490 E-mail: [email protected]
